CV 935A


 Combination Gas Control CV 935A


- Combination gas control include a manual valve

  for safety shut- off.

- Two automatic solenoid shut-off valves with fixed pressure

  regulator on the second automatic valve for ON-OFF operation.

- Solenoid operated pilot valve and burner valve by

  normal control or through remote handset for flame ignition.

- Pilot outlet flow adjustment

- Main outlet pressure adjustment

- Outlet Pressure Adjustment Range:

  NG 1.7"~3.5" W.C. / LPG 5.5"~10" W.C.

- Maximum Inlet Pressure: 35 mbar

- Flow Capacity (1" W.C. Pressure Drop):

  NG: 150,000 BTU/hr / LPG: 230,000 BTU/hr.

- Operating Temperature: -40°C~80°C
